TP-Link ES220GP
Punto de acceso Wi-Fi 7 de banda triple con montado en techo para redes empresariales de alta velocidad
Wi-Fi 7Tri-BandPoE++Fanless40 GbpsZero-Touch
El TP-Link ES220GP redefine la conectividad empresarial con su arquitectura de banda triple y tecnología Wi-Fi 7. Ofrece velocidades de hasta 1376 Mbps en 2,4 GHz, 5760 Mbps en 5 GHz y 11520 Mbps en 6 GHz, garantizando una experiencia de red fluida y sin interrupciones para todos los usuarios.
Diseñado para entornos exigentes, este equipo cuenta con protección contra sobretensiones de 6 kV y un sistema de gestión centralizada a través de la nube o la aplicación Omada. Su instalación es sencilla gracias al soporte Zero-Touch, permitiendo una configuración rápida y segura sin necesidad de intervención manual constante.
Especificaciones técnicas
SOFTWARE-FUNKTIONEN
Quality of ServicePort-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control ?Layer2-FunktionenStatic Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDPLayer2-MulticastIGMP Snooping - IGMP v1/v2/v3 Snooping - Fast LeaveVLANMTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VIDÜbertragungsmethodeStore-And-ForwardOmada AppYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Centralized ManagementOmada Cloud-Based Controller • Omada Hardware Controller • Omada Software ControllerCloud AccessYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Zero-Touch ProvisioningYes. Requires the use of Omada Cloud-Based ControllerManagement FeaturesWeb-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery † • Batch Configuration † • Batch Firmware Upgrading † • Unified Configuration †ZertifizierungFCC, CE, RoHSVerpackungsinhaltES220GP • Power Cord • Mounting Brackets • Rubber Feet • Screws • Installation GuideUmgebungOperating Temperature: -5?~40? (23°F~104°F) • Storage Temperature: -40?~70? (-40?~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
Características
Schnittstelle18× 10/100/1000 Mbps PoE+ RJ45 Ports (16× 802.3af/at-compliant PoE+) • 2× Gigabit SFP Slots • Auto-Negotiation/Auto MDI/MDIXAnzahl LüfterFanlessInstalaciónDesktop/RackmountPhysischer Diebstahlschutz√Spannungsversorgung100–240V AC, 50/60Hz 2.5APoE-PortsStandard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 16 Ports • PoE Budget: 150W available for all PoE+ ports, 30W max per port • Fast PoE & Perpetual PoE • PoE Auto Recovery ‡ • Up to 250m PoE transmission distanceAbmessungen (B*T*H)11.6 × 7.1 × 1.7 in (294 × 180 × 44 mm)Surge Protection±6 kVSwitchingkapazität40 GbpsPaketweiterleitungsrate29.76 MppsMAC-Adresstabelle8KPaketpufferspeicher4 MbitJumbo-Frames15 KBEasy to UseSupports plug-and-play for instant connectivity and simple configuration for additional features
