Huawei Ekit Datacom S310-48HP4X Switch Capa 3 48 Puertos Gigabit Poe / Stack Inteligente / PoE / Poe+ Budget 849 W

Huawei eKit Datacom S310-48HP4X Switch de red gestionable de capa 3 con 48 puertos Gigabit y alimentacion PoE+ 48 puertos Gigabit PoE+ 849 W Stack Inteligente Capa 3 MTBF 46.89 anos 1 U de altura Este switch de red de la linea eKit Datacom de Huawei ofrece una solucion robusta para redes empresariales exigentes. Cuenta con 48 puertos Gigabit integrados y una capacidad de alimentacion PoE+ de hasta 849 W, ideal para conectar dispositivos como telefonos IP y puntos de acceso sin necesidad de fuentes de alimentacion externas. Su arquitectura de capa 3 permite un direccionamiento IP directo en los puertos, facilitando la segmentacion de red y el control de trafico avanzado. Diseñado para operar en entornos exigentes, soporta temperaturas de funcionamiento de 5 a 50 grados Celsius y altitudes de hasta 5000 metros. Su chasis de metal y sistema de enfriamiento por aire garantizan una disipacion eficiente del calor, mientras que su alta disponibilidad MTBF de 46.89 anos asegura una operacion continua y fiable. La gestion simplificada y la compatibilidad con protocolos estandar lo convierten en una pieza clave para infraestructuras de red modernas. Especificaciones técnicas Alimentación Typical power consumption [W] 52.78 W Consumo máximo Without PoE: 74.66 W Full PoE load: 991.74 W (PoE: 846 W) Static power consumption [W] 36.75 W Number of power slots 1 Redundant power supply No compatible Modo de alimentación Pluggable power supply Tensión de entrada AC input: 100 V AC to 240 V AC, 50/60 Hz High-voltage DC input: 240 V DC Rango de tensión de entrada AC input: 90 V AC to 290 V AC 45 Hz to 65 Hz High-voltage DC input: 190 V DC to 290 V DC Maximum input current [A] The current specifications are related to the pluggable power module. For details, see Pluggable Power Modules. Power supply surge protection [kV] Differential mode: ±6 kV common mode: ±6 kV PoE Compatible Red y protocolos Console port RJ45 Eth Management port No compatible USB Compatible Service port surge protection [kV] Common mode: ±6 kV 802.3af (15.4 W per port) 48 802.3at (30 W per port) 28 802.3at (30 W per port) 25 Dimensiones y montaje Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.) Dimensions with packaging (H x W x D) [mm(in.)] 185.0 mm x 650.0 mm x 550.0 mm (7.28 in. x 25.59 in. x 21.65 in.) Chassis material Metal Weight without packaging [kg(lb)] 5.83 kg (12.85 lb) Weight with packaging [kg(lb)] 8.04 kg (17.72 lb) General Item Specification Chassis height [U] 1 U Typical heat dissipation [BTU/hour] 180.09 BTU/hour Maximum heat dissipation [BTU/hour] Without PoE: 254.75 Full PoE load: 3383.92 Availability > 0.99999 Number of card slots 0 Number of fans modules 2 RTC No compatible RPS input No compatible Types of fans Integrado Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left, front, and right and air exhaust from rear MTBF 46.89 years Certificaciones EMC certification Safety certification Manufacturing certification Condiciones de uso Noise at normal temperature (acoustic power) [dB(A)] 67 dB(A) Noise at normal temperature (acoustic pressure) [dB(A)] 55 dB(A) Temperatura de funcionamiento 5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) Temperatura de almacenamiento –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Grado de protección IP20 Almacenamiento Memory 2 GB Flash memory Physical space: 1 GB
