Dahua DHI-NVR2208-I2
Grabadora de vídeo de red con procesador industrial y capacidades avanzadas de Inteligencia Artificial para detección facial y protección perimetral.
6 canales 1080pDetección facialReconocimiento facialProtección perimetralSMD PlusH.265+
Esta grabadora de red Dahua incorpora un procesador industrial de grado empresarial y un sistema operativo Linux embebido para garantizar un funcionamiento estable. Su potente motor de decodificación permite gestionar hasta seis canales en 1080p simultáneamente, optimizando el rendimiento del sistema.
Destaca por sus capacidades de Inteligencia Artificial integradas, capaces de detectar y reconocer rostros, así como de proteger perímetros contra intrusiones. Dispone de hasta diez bases de datos faciales con capacidad para 5.000 imágenes, además de funciones avanzadas como SMD Plus para filtrar falsas alarmas causadas por hojas o lluvia.
Especificaciones técnicas
General
AI by CameraFace detection; face recognition; perimeter protection; SMD PlusAI by DeviceFace detection; face recognition; perimeter protection; SMD PlusPerimeter Performance AI by Device(Number of Channels)1Perimeter Performance of AI by Camera (Number of Channels)4Face Attributes6 attibutes: Gender; age group (6); glasses; expressions (8); mouth mask; beardSMD Plus by Device4SMD Plus by Camera6-channel SMD Plus (AI by camera): Detects tripwire and intrustion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness awayAccess Channel8 channelsDecoding CapabilityAI disabled: 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps AI enabled: 1-channel 8MP@30 fps; 1-channel 5MP@30 fps; 2-channel 4MP@30 fps; 4-channel 1080p@30 fpsThird Party Camera AccessOnvifMobile Phone AccessAndroid; iOSMulti-channel PlaybackUp to 8 channelsRecord ModeManual record; alarm recordings; motion detection recordings; scheduled recordingsBackupUSB devicePlayback Function1. Play; pause; stop; fast forward; fast backward; rewind; play by frame 2. Full screen; backup (vide clip/file); partially zom in; audio on/offHDD2 SATA ports, up to 10 TB. The maximum HDD capacity varies with environment temperatureHDMI1 (max. resolution: 4K)VGA1RCA Input1RCA Output1> Max. decoding capability6 × 1080p@30 fps. Supports adaptive decoding> AI by cameraFace detection and recognition, perimeter protection, and SMD PlusResolución12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1Multi-screen Display1, 4, 8, 9 viewsCertificationsFCC:47 CFR FCC Part15,SubpartB,Class A CE-EMC:EN 55032:2015,Class A;EN IEC 61000-3-2:2019;EN 61000-3-3:2013+A1:2019;EN 55024:2010+A1:2015;EN 55035:2017;EN 50130-4:2011+A1:2014 CE-LVD:EN 62368-1:2014+A11:2017
Condiciones de uso
Temperatura de funcionamiento–10 °C to +55 °C (+14 °F to +131 °F)Temperatura de almacenamiento0 °C to 40 °C (32 °F to 104 °F)Humedad de funcionamiento10%–93%Humedad de almacenamiento30%–85%Operating Altitude3,000 m (9,842.52 ft)
Red y protocolos
Operation InterfaceWeb; local GUINetwork Bandwidth80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding.Protocolos de redHTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P;Auto RegistrationInteroperabilidadONVIF (profile T; profile S; profile G); CGI; SDKNavegadorChrome; IE9 or later; FirefoxUSB1 × front USB2.0; 1 × back USB2.0Network1 × RJ-45 (10 or 100 Mbps)
Dimensiones y montaje
Peso neto1.51 kg (3.33 lb)Peso bruto2.76 kg (6.08 lb)Dimensiones375 mm × 284.3 mm × 53 mm (14.76" × 11.19" × 2.09") (W × L × H)Package Dimensions141 mm × 433 mm × 366 mm (5.55" × 17.05" × 14.41") (W × L × H)InstalaciónDesktop
Detección y alarmas
Alarmas generalesMotion detection; privacy masking; video loss; PIR alarm; IPC alarmAnomaly AlarmCamera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exceptionIntelligent AlarmFace detection; face recognition; perimeter protection (intrusion and tripwire); IVS; SMD PlusAcciones ante alarmaRecording; snapshot; buzzer; log; preset; email; tour
Vídeo y audio
Salida de vídeo1 × VGA, 1 × HDMI (simultaneous)VideoSmart H.265+; H.265; Smart H.264+; H.264; MJPEGAudioPCM; G711A; G711U; G726
Sistema
Main ProcessorIndustrial-grade embedded processorSistema operativoEmbedded Linux
Almacenamiento
Face Database CapacityUp to 10 face databases with 5,000 imagesAlmacenamientoLocal HDD and network
Alimentación
Alimentación12 V DC, 4 AConsumoTotal output of NVR is ≤ 10 W (without HDD)
