TP-Link TL-SG2016P
Conmutador inteligente JetStream de 16 puertos con 8 puertos Gigabit PoE+
16 puertosPoE+120 WSin ventiladorVLANOmada
Este conmutador inteligente de 16 puertos combina un rendimiento Gigabit completo con una gestión simplificada a través de la suite Omada. Sus ocho puertos PoE+ suministran hasta 120 W de potencia, ideal para alimentar puntos de acceso y cámaras de seguridad sin necesidad de fuentes de alimentación externas. Gracias a su diseño sin ventilador, garantiza un funcionamiento silencioso y fiable en cualquier entorno de oficina o hogar.
Disfruta de una administración centralizada y remota mediante la aplicación Omada o el controlador en la nube, facilitando la configuración y el monitoreo de toda tu red. Cuenta con funciones avanzadas de seguridad como 802.1X, inspección ARP y control de inundaciones, además de soporte nativo para IPv6 y agregación de enlaces LACP. Su gestión web intuitiva y la detección automática de dispositivos hacen que la implementación sea rápida y sencilla.
Especificaciones técnicas
SOFTWARE FEATURES
Quality of Service802.1p CoS/DSCP priority • 8 priority queues • Priority Schedule Mode - SP (Strict Priority) - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port/Flow-based Rating Limit • Smoother Performance • Storm Control - Multiple Control Modes(kbps/ratio) - Broadcast/Multicast/Unknown-Unicast ControlL2 and L2+ FeaturesDHCP Relay - DHCP VLAN Relay • DHCP L2 Relay • Link Aggregation - Static link aggregation - 802.3ad LACP - Up to 8 aggregation groups and up to 8 ports per group • Spanning Tree Protocol - 802.1D STP - 802.1w RSTP - 802.1s MSTP - STP Security: TC Protect, BPDU Filter/Protect, Root Protect • Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - CPU Mirroring - One-to-One - Many-to-One - Flow-Based - Ingress/Egress/Both • Device Link Detect Protocol (DLDP) • 802.1ab LLDP/ LLDP-MEDL2 Multicast511 IPv4, IPv6 shared multicast groups • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave - IGMP Snooping Querier - Static Group Config • Multicast VLAN Registration (MVR) • Multicast Filtering • MLD Snooping - MLD v1/v2 Snooping - Fast Leave - MLD Snooping Querier - Static Group Config • Limited IP Multicast (256 profiles and 16 entries per profile)IPv6 SupportIPv6 Dual IPv4/IPv6 • Multicast Listener Discovery (MLD) Snooping • IPv6 neighbor discovery (ND) • Path maximum transmission unit (MTU) discovery • Internet Control Message Protocol (ICMP) version 6 • TCPv6/UDPv6 • IPv6 applications - DHCPv6 Client - Ping6 - Tracert6 - Telnet (v6) - IPv6 SNMP - IPv6 SSH - IPv6 SSL - Http/Https - IPv6 TFTPVLANVLAN Group - Max. 4K VLAN Groups • 802.1Q tag VLAN • MAC VLAN: 12 Entries • Protocol VLAN • GVRP • Voice VLANAccess Control ListSupport up to 230 entries • Time-Range - Time Slice - Week Time-Range - Absolute Time-Range - Holiday • Time-based ACL • MAC ACL - Source MAC - Destination MAC - VLAN ID - User Priority - Ether Type • IP ACL - Source IP - Destination IP - IP Protocol - TCP Flag - TCP/UDP Source Port - TCP/UDP Destination Port - DSCP/IP TOS • IPv6 ACL • Combined ACL • Rule Operation - Permit/Deny • Policy Action - Mirror - Rate Limit - Redirect - QoS Remark • ACL Rules Binding - Port Binding - VLAN Binding • Actions for flows - Mirror (to supported interface) - Redirect (to supported interface) - Rate Limit - QoS RemarkSecurityAAA • 802.1X - Port-based authentication - MAC (Host) based authentication - Authentication Method includes PAP/EAP-MD5 - MAB - Guest VLAN - Support Radius authentication and accountability • IP/IPv6-MAC Binding - 512 Binding Entries - DHCP Snooping - DHCPv6 Snooping - ARP Inspection - ND Detection • IP Source Guard - 253 Entries - Source IP+Source MAC • IPv6 Source Guard - 183 Entries - Source IPv6 Address+Source MAC • DoS Defend • Static/Dynamic/Permanent Port Security - Up to 64 MAC addresses per port • Broadcast/Multicast/Unicast Storm Control - kbps/ratio control mode • Port Isolation • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure Command Line Interface (CLI) management with SSHv1/SSHv2 • IP/Port/MAC-based access controlAdvanced FeaturesAutomatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot ScheduleMIBsMIB II (RFC1213) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIBs • RMON MIB(RFC1757, rmon 1,2,3,9)Omada AppYes, through • Omada Cloud-Based Controller • OC300 • OC200 • Omada Software ControllerCentralized ManagementOmada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software ControllerCloud AccessYes, through • Omada Cloud-Based Controller • OC300 • OC200 • Omada Software ControllerZero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based ControllerManagement FeaturesWeb-based GUI • Command Line Interface (CLI) through telnet • SNMPv1/v2c/v3 • SNMP Trap/Inform • RMON (1,2,3,9 groups) • SDM Template • DHCP/BOOTP Client • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • EEE • SNTP • System LogCertificacionesCE, FCC, RoHSPackage ContentsTL-SG2016P • Power Adapter • Installation Guide • Rubber FeetSystem RequirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.EnvironmentOperating Temperature: 0–40 ? (32–104 ?); • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
HARDWARE FEATURES
Standards and ProtocolsIEEE 802.3i, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1xInterfaz16× 10/100/1000 Mbps RJ45 Ports (Ports 1–8 Support 802.3at/af PoE+) • Auto-Negotiation/Auto MDI/MDIXNetwork Media10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)Fan QuantityFanlessAlimentaciónExternal Power Adapter (Output: 53.5 VDC/ 2.43 A)PoE Ports (RJ45)Standard: 802.3af/at compliant • PoE Ports: 8 Ports • Power Supply: 120 WDimensiones11.3 x 4.4 x 1.0 in (286 x 111.7 x 25.4 mm)Consumo máximo146.5 W (110 V/60 Hz) (with 120 W PD connected)Max Heat Dissipation499.98 BTU/hr (110 V/60 Hz) (with 120 W PD connected)Bandwidth/Backplane16 GbpsMAC Address Table8kPacket Buffer Memory4.1 MbitJumbo Frame9 KB
Características
TL-SG2016P8-Port PoE+Full Gigabit Ports8× gigabit PoE+
