TP-Link ES205GP
Interruptor de 5 puertos Gigabit con gestión fácil y 4 puertos PoE+
5 puertos Gigabit4 puertos PoE+65 W de potencia PoEDiseño sin ventiladorCarcasa de aceroIntegración Omada SDN
El interruptor ES205GP de TP-Link ofrece una solución de red robusta y eficiente para entornos de oficina o vigilancia. Con 4 puertos PoE+ de hasta 30 W cada uno y un presupuesto total de 65 W, permite alimentar cámaras IP y puntos de acceso directamente. Su diseño sin ventilador garantiza un funcionamiento silencioso y duradero, ideal para instalaciones donde el ruido es un factor a evitar.
Gestiona tu red de forma sencilla mediante la suite Omada, permitiendo configuración centralizada, descubrimiento automático de dispositivos y actualizaciones de firmware en la nube. Cuenta con funciones avanzadas como prevención de bucles, agregación de enlaces estática y control de calidad de servicio para priorizar el tráfico crítico. Su carcasa metálica resistente soporta montaje en escritorio o pared, adaptándose a cualquier necesidad de infraestructura.
Especificaciones técnicas
SOFTWARE FEATURES
Quality of ServicePort-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control ?L2 FeaturesStatic Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDPL2 MulticastIGMP Snooping - IGMP v1/v2/v3 Snooping - Fast LeaveVLANMTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VIDTransmission MethodStore-And-ForwardOmada AppYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Centralized ManagementOmada Cloud-Based Controller • Omada Hardware Controller • Omada Software ControllerCloud AccessYes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.Zero-Touch ProvisioningYes. Requires the use of Omada Cloud-Based ControllerManagement FeaturesWeb-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery † • Batch Configuration † • Batch Firmware Upgrading † • Unified Configuration †CertificacionesFCC, CE, RoHSPackage ContentsES205GP • Power Adapter • Installation Guide • Rubber FeetEnvironmentOperating Temperature: 0?~40? (32?~104?) • Storage Temperature: -40?~70? (-40?~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
HARDWARE FEATURES
Interfaz5× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at PoE+ and 802.3af PoE) • Auto-Negotiation/Auto MDI/MDIXFan QuantityFanlessInstalaciónDesktop • Wall MountPhysical Security Lock√AlimentaciónDC Power Adapter (Output: 53.5 VDC/ 1.31 A)PoE Ports (RJ45)Standard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 4 ports • PoE Budget: 65 W available for all PoE+ ports, 30W max per port • PoE Auto Recovery ‡ • Up to 250m PoE transmission distanceDimensiones3.9×3.9×1.0 in (100×98×25 mm)Switching Capacity10 GbpsPacket Forwarding Rate7.4 MppsMAC Address Table8KPacket Buffer Memory4 MbitJumbo Frame15 KB
Características
5× 10/100/1000Mbps RJ45 ports (4× 802.3at/af-compliant PoE+)65W Power Budget, with up to 30W for each PoE portEasy to UseSupports plug-and-play for instant connectivity and simple configuration for additional featuresCentralized Cloud Management via the web or the Omada app†Up to250m PoE**, QoS?, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networkingAutomatic Loop Prevention, VLAN, and IGMP SnoopingFanless design for silent operationDurable metal casing and desktop/wall mounting design
