Dahua DHI-NVR5232-8P-EI
Grabadora de video industrial con procesador de grado industrial y sistema Linux para gestión avanzada de seguridad.
Procesador industrialSistema Linux8 puertos PoEDetección facialReconocimiento facialProtección perimetralANPRSMD Plus
Este grabador Dahua integra capacidades de inteligencia artificial para la detección y reconocimiento de rostros, análisis de atributos humanos y vehículos, así como protección perimetral inteligente. Su tecnología SMD Plus reduce falsas alarmas causadas por condiciones ambientales, optimizando la vigilancia en entornos complejos.
Dispone de múltiples canales para el análisis de metadatos, conteo de personas y análisis estereoscópico. Con soporte para hasta 32 cámaras y decodificación de alta resolución, garantiza un rendimiento fluido incluso con flujos de video de alta definición, ideal para instalaciones de seguridad críticas.
Especificaciones técnicas
General
AI by RecorderFace detection; face recognition; perimeter protection; SMD PlusAI by CameraFace detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat mapAcuPick AI by Camera + RecorderMax. 16-channel, 1 combined event per channel/sPerimeter Performance AI by Recorder (Number of Channels)4 channels, 10 IVS rules for each channelPerimeter Performance of AI by Camera (Number of Channels)16 channelsFace AttributesGender; age group; glasses; expressions; face mask; beardSMD Plus by Recorder8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition changeSMD Plus by Camera16 channelsMetadata Performance of AI by Camera (Number of Channels)8 channelsHuman AttributesTop color, top type, bottom color, bottom type, hat, bag, age, gender and umbrellaMotor Vehicle AttributesLicense plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.Non-motor Vehicle AttributesVehicle model, vehicle color, number of persons, helmet.ANPR by Camera (Number of Channels)8 channelsAccess Channel32Decoding CapabilityAI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps AI enabled: 1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fpsThird-party Camera AccessONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; SamsungMobile Phone AccessiOS; AndroidMulti-channel PlaybackUp to 16 channelsRecord ModeGeneral, motion detection; intelligent; alarm; POSBackup MethodUSB device and networkPlayback ModeInstant playback, general playback, event playback, tag playback, smart playback (face and motion detection)Disk GroupSíRS-2321RS-4851HDMI1VGA1Resolución32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIFMulti-screen DisplayMain screen: 1/4/8/9/16/25/36 Sub screen: 1/4/8/9/16CertificationsFCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
Dimensiones y montaje
Peso neto2.57 kg (5.67 lb)Peso bruto3.8 kg (8.38 lb)Dimensiones375.0 mm × 329.4 mm x 53.0mm (14.76" × 12.97" × 2.09") (W × D × H)Packaging Dimensions451.0 mm × 147.0 mm × 425.0 mm (17.76" × 5.79" × 16.73") (W × D × H)InstalaciónRack or desktop
Red y protocolos
Operating InterfaceWeb, Local GUINetwork BandwidthAI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoingProtocolos de redHTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSIInteroperabilidadONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDKNavegadorChrome;IE;Safari;Edge;FirefoxHDD Interface2 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature.USB2 (1 front USB 2.0 port, 1 rear USB 3.0 port)Puerto de red1(10/100/1000 Mbps Ethernet port, RJ-45)PoE Port8 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE
Detección y alarmas
Alarmas generalesMotion detection; privacy masking; local alarmAnomaly AlarmCamera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exceptionIntelligent AlarmFace detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat mapAcciones ante alarmaRecord; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; emailEntrada de alarma4 channelsSalida de alarma2 channels
Vídeo y audio
Salida de vídeo1 VGA, 1 HDMI VGA:1920 × 1080, 1280 × 1024, 1280 × 720 HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous video source output for HDMI and VGACompresión de vídeoSmart H.265+; H.265; Smart H.264+; H.264; MJPEGCompresión de audioG.711a; G.711u; PCM; G726Entrada de audio1-channel RCASalida de audio1-channel RCA
Condiciones de uso
Temperatura de funcionamiento–10 °C to +55 °C (14 °F to +131 °F)Temperatura de almacenamiento–20 °C to +60 °C (–4 °F to +140 °F)Humedad de funcionamiento10%–93% (RH)
Sistema
Main ProcessorIndustrial-grade processorSistema operativoEmbedded Linux
Almacenamiento
Face Database CapacityUp to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.License Plate Database Capacity1. Create up to 20,000 plate numbers. 2. Blocklist and allowlist
Alimentación
Alimentación100–240 VAC, 47-63 HzConsumoTotal output of NVR is ≤ 10 W (without HDD) Total output power of PoE is 130 W, the maximum output power of a single port is 25.5W
