Dahua DH-IPC-HFW5442EP-ZHE-2712
Cámara IP de exterior con detección facial y conteo de personas
IP67PoE+H.265+4 MPSmart CodecFace Detection
Esta cámara Dahua de 4 megapíxeles integra tecnologías avanzadas de inteligencia artificial para la seguridad perimetral. Su sensor CMOS de 1/1.8 pulgadas captura imágenes detalladas incluso en condiciones de baja iluminación, gracias a su capacidad de funcionamiento con apenas 0.003 lux.
Disfruta de una versatilidad operativa sin precedentes con codificación flexible y soporte para múltiples flujos de video. La protección perimetral inteligente permite configurar zonas de interés y detectar intrusiones, vehículos o aglomeraciones de personas con gran precisión.
Especificaciones técnicas
Imagen y óptica
Sensor de imagen1/1.8” 4Megapixel progressive scan CMOSResolución máxima2688 (H) × 1520 (V)Sistema de exploraciónProgressiveObturador electrónicoAuto/Manual, 1/3 s–1/100000 sRelación señal/ruido> 56 dBIluminación mínima0.003 [email protected]Distancia de iluminaciónDistance up to 50 m (164 ft)Control de iluminadoresAuto/ManualNúmero de iluminadores4(IR LED)Tipo de objetivoMotorized vari-focalDistancia focal2.7 mm–12.0 mmApertura máximaF1.8Aperture TypeAutoDistancia mínima de enfoque1.2 m (3.94 ft)Resolución2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240)Día y nocheAuto(ICR)/Color/B/WBLC ModeBLC/HLC/WDR (140 dB)Balance de blancosAuto/Natural/Street Lamp/Outdoor/ManualControl de gananciaAuto/ManualReducción de ruido3D DNRElectronic Image Stabilization (EIS)SíSmart IlluminationSíAntinieblaSíEspejoOff/OnMáscara de privacidadOff/On (4 Area, Rectangle)
Vídeo y audio
Flujo secundarioD1 (1 fps–25/30 fps)Tercer flujo1080P (1 fps–16 fps)CompresiónH.265,H.264,H.264B,H.264H, MJPEG (only supported by sub stream)Smart CodecSmart H.265+/ Smart H.264+Streaming Capability3 StreamsFotogramas por segundoMain Stream: 2688×1520 (1 fps–25/30 fps) 2560×1440 (1 fps–25/30 fps) 1920×1080 (1 fps–50/60 fps)Control de tasa de bitsCBR/VBRBit RateH.264: 32 Kbps–8192 Kbps H.265: 19 Kbps–8192 KbpsCompresión de audioG.711a, G.711Mu, AAC, G.726, G.723Audio Interface1/1 channel In/Out
Red y protocolos
> Multiple network monitoringWeb viewer, CMS (DSS/PSS) & DMSSNetworkRJ-45 (10/100Base-T)SDK and APISíProtocolosIPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMPNavegadorIE (versions newer than IE8), Chrome, Firefox, Safari (versions newer than Safari 12)
Almacenamiento
RAM/ROM1 GB/128 MBAlmacenamientoNAS;FTP;SFTP;Dahua Cloud Micro SD card 256 GBStorage Conditions40° C to +60° C (-40° F to +140° F)
General
()Angle of ViewH: 114°–47°, V: 62°–26°Perimeter ProtectionTripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detectionPeople CountingSupport the counting of enter number, leave number, and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarmEvent TriggerMotion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomalyGeneral IntelligenceObject Abandoned/MissingHeat MapSíRegion of InterestOff/On (4 Zone)Flip0°/90°/180°/270°User/Host20 UsersMobile PhoneiOS, AndroidCondiciones de funcionamiento40° C to +60° C (-40° F to +140° F)/Less than 95% RHProtection GradeIP67,IK10Software de gestiónSmart PSS, DSS, DMSSCertificationsCE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Dimensiones y montaje
Mount TypeBoard-inGiro, inclinación y rotaciónPan: 0˚–360˚; Tilt: 0˚–90˚; Rotation: 0˚–360˚CarcasaMetal, plasticDimensiones273.2 mm × 95.0 mm × 95.0 mm (10.76” × 3.74” × 3.74”)Peso neto1.11 kg (2.44 lb)Peso bruto1.51 kg (3.33 lb)
Detección y alarmas
Face DetectionFace detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo;three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time settingDetección de movimientoOff/On (4 Zone, Rectangle)Alarm EventNo SD card;SD card full;SD card error;network disconnection;IP conflict;illegal access;motion detection;video tampering;Defocus Detection;scene changing;intrusion;tripwire;abandoned object;missing object;fast moving;parking detection;loitering detection;people gathering;audio detection;people counting;face detection;voltage detection;People counting in area;Stay alarm;People No. exception detection;Queue ManagementAlarma2 channel In: 5mA 5V DC 1 channel Out: 300mA 12V DC
Alimentación
AlimentaciónDC 12V ( ±30% ), PoE+ (802.3at)Consumo< 15.2W
