Dahua DH-IPC-HF5842FP-ZE-S2
Cámara IP de 8 MP con sensor CMOS 1/1.8", ideal para entornos de baja luminosidad y alta definición.
8 MPH.265+WDR 120dBPoEMic integradoeSIM
Esta cámara de Dahua ofrece una resolución de 3840 x 2160 píxeles gracias a su sensor CMOS de 1/1.8 pulgadas. Cuenta con tecnología WDR de 120dB y reducción de ruido 3D para capturar imágenes nítidas incluso en condiciones de iluminación difíciles o con alto contraste.
Dispone de funciones inteligentes avanzadas como detección facial, conteo de personas y mapas de calor. Su compresión Smart H.265+ optimiza el ancho de banda y el almacenamiento, mientras que el soporte para tarjetas Micro SD de hasta 256 GB asegura una grabación local fiable y segura.
Especificaciones técnicas
Imagen y óptica
Sensor de imagen1/1.8”CMOSResolución máxima3840 (H) × 2160 (V)Sistema de exploraciónProgressiveObturador electrónicoAuto/Manual 1/3 s–1/100,000 sIluminación mínimaWith 10.5 mm–42 mm lens: 0.004 [email protected] (Color, 30 IRE) 0 lux (Illuminator on)Relación señal/ruido>56 dBResolución3840 × 2160; 3072 × 2048; 3072 × 1728; 2592 × 1944; 2688 × 1520; 2048 × 1536; 2304 × 1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)Compensación de contraluz (BLC)SíAtenuación de luces intensas (HLC)SíRango dinámico amplio (WDR)120dBBalance de blancosAuto; natural; street lamp; outdoor; manual; regional customControl de gananciaAuto; manualReducción de ruido3D NRRegion of Interest (RoI)Yes (4 areas)Image StabilizationElectronic Image Stabilization (EIS)AntinieblaSíImage Rotation0°/90°/180°/270° (Support 90°/270° with 4 M resolution and lower)EspejoSíMáscara de privacidad8 areas
Red y protocolos
Puerto de redRJ-45 (10/100 Base-T)SDK and APISíProtocolos de redIPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMPInteroperabilidadONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2PNavegadorIE: IE8 and later Chrome FirefoxMobile ClientiOS; Android
Detección y alarmas
Face DetectionFace detection; track; snapshot optimization; snapshot; face enhancement; face exposure; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimized snapshot, quality priority snapshot; face angle filter; optimization time settingDetección de movimientoOFF/ON (4 areas, rectangular)Alarm EventNo SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; defocus detection; scene changing; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; loitering detection; people gathering; input abnormal detection; intensity change detection; people counting; face detection; people counting in area; stay alarm; people No. exception detection; queue managementEntrada de alarma2 channels in: 5 mA 3V–5 VDCSalida de alarma2 channels out: 300 mA 12 VDC
Almacenamiento
Memoria ROM128 MBMemoria RAM1 GBAlmacenamientoFTP; SFTP; Micro SD card (Support max. 256 G); NAS
Vídeo y audio
Compresión de vídeoH.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)Smart CodecSmart H.265+/H.264+Fotogramas por segundoMain stream: 3840× 2160 (1 fps–25/30 fps) Sub stream: D1 (1 fps–25/30 fps) Third stream: 1080p (1 fps–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacityStream Capability3 streamsControl de tasa de bitsCBR/VBRTasa de bits de vídeoH.264: 3 kbps-20480 kbps H.265: 3 kbps-20480 kbpsMicrófono integradoSíCompresión de audioPCM; G.711a; G.711Mu; G.726; G.723Entrada de audio1 channel (3.5 mm JACK port)Salida de audio1 channel (3.5 mm JACK port)
General
IVSAbandoned object; missing objectHeat MapSíIVS (Perimeter Protection)Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detectionPeople CountingSupport the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports. Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm. Support queue management, and 4 rules configuration. Count number of people or stay time and link alarmIntelligent SearchWork together with Smart NVR to perform refine intelligent search, event extraction and merging to event videosCyber SecurityVideo encryption; configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgradeUser/Host20 (Total bandwidth: 80 M)Software de gestiónSmart PSS; DSS; DMSSCertificationsCE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Dimensiones y montaje
Mount TypeC/CSCarcasaMetalDimensiones161.6 mm × 86.8 mm × 74.0 mm (6.4” × 3.4” × 2.9”)Peso neto800 g (1.8 lb)Peso bruto900 g (2.0 lb)
Alimentación
Alimentación12 VDC (±25%)/24V AC (±30%)/PoE (802.3at)/ePoEConsumoBasic power consumption: 7.9W (12 VDC); 9.3 W (24 VAC); 9.9W (PoE) Max. power consumption (H.265 + max. stream + intelligent function): 10.5W (12 VDC); 12.3 W (24 VAC); 13.1W (PoE)
Condiciones de uso
Temperatura de funcionamiento–30 °C to +60 °C (–22 °F to +140 °F)/Less than 95% RHTemperatura de almacenamiento–30 °C to +60 °C (–22 °F to +140 °F)
